Projecta DC/DC & Solar Charger IDC45

PIDC45

Notify me when this product is available:

45A 3 STAGE INTELLI-CHARGE 9-32V DEEP CYCLE DUAL BATTERY CHARGER - IDC45

Ideal for the larger power requirements of caravans, motor homes and trucks, the IDC45 sets a new benchmark for DC-DC battery management, providing unrivalled performance and features.

Jay-Dee Part #: PIDC45

Pack Qty: 1

Brand: Projecta IDC45

  • Engine bay installation: Sealed to IP67, the IDC is dust, splash and shock proof and can safely operate in extreme temperatures up to 80°C
  • Dual charging modes: Engineered to work with both smart and conventional alternators
  • Multi-chemistry: Set the charging profile to suit battery chemistry type - Wet, Calcium AGM or Gel
  • Dual input operation: Simultaneous dual battery charging from both solar and alternator inputs
  • Total safeguard protection: Over temperature, reverse connection, over/under and spark free protection

Charge Type: 3 Stage

Alternator Input Voltage: 9-32Vdc

Max Solar Input: 28Vdc, 693W

Output Current:

Input 9-11Vdc 37A,

Input 11-32Vdc 45A



Back Drain on AUX Battery: <5mA

Charger Control: Gel 14.1V, AGM 14.4V,Wet 14.7V,Calcium 15.4V

Battery Capacity: 150-600Ah

Batteries Supported: Gel, AGM, Wet & Calcium

Smart Alternator:

12V Turn On: 12.2-20V, Turn Off: <11.9V

24V: Turn On: 24.4-32V Turn Off: <24V



Conventional Alternator:

12V: Turn On: 13.4-20V Turn Off: <12.8V

24V: Turn On: 26.8-32V Turn Off: <25.6V



Operating Temperature: -10°C to +80°C
