Mini Blade Fuse/Relay Box Kit- 9 Way Waterproof

RFB9K

5 items left

Mini Blade Fuse/Relay Box Kit- 9 Way Waterproof

Accepts any mini (280 style) circuit protection component


Max Fuse Rating: 30A per circuit

Max Continuous Current: 100A at 23 °C, 70A at 85 °C

Number of Cavities: 18

Recommended Mounting: M6 bolt and lock washer

Mounting Bracket Torque: 5.5-6.5 Nm

Temperature Range: -40 °C to +105 °C

Ingress Protection Rating: IP67/IP69K

Dimensions: 80.4 x 69.8 x 45.2 mm

Wire Sizes: 0.35 - 3.00 mm²

Terminals & Seals:

  • Seal: Silicon Rubber WPS-BLUE x 18 (Included)
  • Cavity Plug: Silicon Rubber WPCP x 5 (Included)
  • Terminals: Tinned Brass MP280FT-12G x 18 (Included)

Fuses and relays not included.



Recommended Crimping Tools:

IWS-1424B

IWS-1424BN
